Pickling and Electrolytic polishing Wire Wrapped Wedge Wire Water Well Pipe Collapse Strength 450
water well screen pipe, johnson well screeen, rod based wire wrapped screen, wedge wire screen, stainless steel strainer pipe, v wire slot tube, perfect roundness well screen pipe, dewatering well screen, stainless steel lateral screens, wedge wire filter candles, Rotary drum screens, strainer cylinder, sand control well screen, oil well screen, rod based continuous slot screens, header and hub laterals & hub radial laterals etc.
The welded water well screen pipe is made up of rods and warp. The rod can be round wire, triangular wire or trapezoid wire. The warp is triangular wire (V-shaped wire). Water well screens have a structure and high open area, as well as accurate slot dimension. At the same time, water well screen have heat-resisting, anti-corrosive, good machine capability, last long, safety and reliability and so on characteristics. It can be used in many kinds of medium filtering.
Wire Wrapped Wedge Wire Water Well Screen Description:
1. Well Screen Pipe material: stainless steel 304, 316, 316L, 321, 201, Duplex stainless steel, galvanized low-carbon steel, or custom materials
2. Slot opening size: 0.1mm-15mm
3. Diameter (inches): 2, 3, 4, 5, 6, 8, 10, 12, 14, 16, 20, 29-1000mm
4. Length: 2.9m, 5.85m. (10ft, 20ft))
5. Connection method: beveled, circumferential welded, threaded connection, flange, end cap
6. Flow type: FOTI, FITO
7. Usage: This screen pipe is applicable in vertical wells, deviated wells, directional wells, and others that require sand control.
Quality assurance
1.Every production process has a special person to test to ensure quality
2. Have professional engineers to check the quality
Package:
1. Plastic bubble bag packaging
2. Transparent plastic bag inside, woven bag outside
3. Wooden box
4. Pallet
FAQ
Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: 3-5 days for Sample preparing , 15-25 working days for mass production.
Q3. Do you have any MOQ limit for the order?
A: Low MOQ, 3pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: Airline, sea shipping and rail transportation are all optional.
Or ship by EMS, DHL, UPS, FedEx or TNT, it takes 5-7 days to arrive.
Q5. How to proceed an order?
A: Firstly let us know your need specification or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on the product?
A: Yes. Please inform us formally before our production.
Technological Parameters of Wedge Wire Screen Pipe
| Size | Inside Diameter (ID) | Outside Diameter (OD) | Female Thread OD |
| Inch | Mm | Inch | Mm | Inch | Mm | Inch | mm |
| 2 | 51 | 2 | 51 | 2 5/8 | 67 | 2 3/4 | 70 |
| 3 | 76 | 3 | 76 | 3 5/8 | 92 | 3 3/4 | 95 |
| 4 | 102 | 4 | 102 | 4 5/8 | 117 | 4 3/4 | 121 |
| 5 | 127 | 5 | 127 | 5 5/8 | 143 | 5 3/4 | 146 |
| 6 | 152 | 6 | 152 | 6 5/8 | 168 | 7 | 178 |
| 8 | 203 | 8 | 203 | 8 5/8 | 219 | 9 1/4 | 235 |
| 10 | 254 | 10 | 254 | 10 3/4 | 273 | 11 3/8 | 289 |
| 12 | 305 | 12 | 305 | 12 3/4 | 324 | 13 3/8 | 340 |
| 14 | 356 | 13 1/8 | 333 | 14 | 356 | | |
| 16 | 406 | 15 | 381 | 16 | 406 | | |
| 20 | 508 | 18 3/4 | 476 | 20 | 508 | | |
| PROFILE WIRE | | | | | | | | |
| WIDTH(mm) | 1.50 | 1.50 | 2.30 | 2.30 | 1.80 | 3.00 | 3.70 | 3.30 |
| HEIGHT(mm) | 2.20 | 2.50 | 2.70 | 3.60 | 4.30 | 4.70 | 5.60 | 6.30 |
| SUPPORT ROD | | | | | |
ROUND |
| WIDTH(mm) | 2.30 | 2.30 | 3.00 | 3.70 | 3.30 | Ø2.5--Ø5mm |
| HEIGHT(mm) | 2.70 | 3.60 | 4.70 | 5.60 | 6.30 | ---- |
Wedge Wire Screen Pipe Manufacturing Steps
